BETA 550 BRONZE80 PLUS Bronze Certified |
BETAAn excellent choice for your system building and upgradingBeta series offers modern design of power supply and 80 PLUS Bronze efficiency. It incorporates main Japanese capacitor and provide continuous power at the most competitive price point. |
High Quality Compoents
Japanese Main Capacitors
Beta series adopts Japanese main industrial level electronic capacitors for high durability, also achieve tight voltage and low ripple noise to enhance performance. Along with other high - quality Components in the power supply, resulting stable wattage output and reliable performance.
80 Plus Bronze Certified
Montech Beta series provides high efficiency up to 80% and is certified to 80 PLUS® Bronze. Also, the series has been optimized with all generations of Intel's & AMD's processors to maximize energy saving.
Efficiency
Effective energy saving, it can effectively reduce the energy consumption, and reach 83% conversion efficiency.
Powerful Single +12V Rail
Powerful single rail +12 V provides a stable and reliable supply to Graphics Cards and other pc components
120MM silent fan
High quality fan provides strong airflow with low noise, which makes low temperatures and quiet operation.
Cables
Beta series offers sufficient amount of cables. Also, the length of the cables are longer which makes building easier.
|
M/B 20+4 Pin |
1 |
|
CPU 4+4 Pin |
1 |
|
PCIE 6+2 Pin |
2 |
|
SATA |
6 |
|
Molex 4Pin |
2 |
HARDWARE PROTECTION
|
OPP UVP OVP SCP |
3 year warrantyBeta series offers 3 year warranty since the date of purchase. "Warranty service doesn't extend to power supply used for Bitcoin Miner." |
Trustworthy Manufacturing, Dedicated to Outstanding Products.Montech is committed to the development of PC gaming chassis, power supplies and cooling to the highest standards. Our designs and attention to quality is like none other. We strive to bring the best price to performance ratio to consumers.
Over 30 Years of Industry Experience.-Excellence is our Reputation- Being a part of the PC industry for over 30 years, Telon is proud to present it’s PC Gaming brand Montech! |
Each Montech Power Supply goes through strenuous quality testing on the highest end equipment before they are shipped out to you.
Specifications
|
Product Name |
BETA 550 |
|
|
ATX Version |
ATX12V |
|
|
PFC |
Active PFC (>0.9 typical) |
|
|
Input Voltage |
100-240Vac |
|
|
Input Current |
8A |
|
|
Input Frequency |
47-63Hz |
|
|
Dimensions (L*B*H) |
140*150*86mm |
|
|
Fan Size |
120mm |
|
|
Hold Up Time |
10msec (minimum) at 80% of full load at 230Vac input. |
|
|
Efficiency |
83% Typically |
|
|
MTBF |
>100,000 Hours |
|
|
Operating Temperature |
0-45°C |
|
|
Protections |
OVP / OPP / UVP / SCP |
|
|
Regulatory |
cTUVus / TUV / CB / CE / CCC / RoHS / FCC |
|
|
Connectors |
M/B 20+4Pin |
1 |
|
CPU 4+4Pin |
1 |
|
|
PCIE 6+2 |
2 |
|
|
SATA |
6 |
|
|
Molex 4Pin |
2 |
|
|
AC Input |
100-240Vac 47-63Hz 8.0A |
||||
|
DC Output |
+3.3V |
+5V |
12V |
-12V |
+5VSB |
|
Max. Output Current |
18A |
16A |
42A |
0.3A |
2.5A |
|
Max. Output Power |
110W |
504W |
3.6W |
12.5W |
|
|
Total POWER |
550W |
||||
